Most lounger spas start at 2260×2260mm. The V1005 shrinks that to 2130×2130mm while keeping the lounger's full 1900mm length. You get zero-gravity floating without losing your entire patio to the spa.
Multi-layer insulation (shell, pipe wraps, cabinet foam, base pan) retains heat in freezing weather. The 304 stainless steel frame won't corrode from winter road salts or coastal spray.
Parameter | Specification |
Model | V1005 |
Dimensions (L x W x H) | 2130*2130*920mm |
Seating Capacity | 5 adults |
Lounge Seat (s) | 1 adult |
Water Capacity | 1,391 liters |
Dry Weight | 420 kg |
Filled Weight | 1,811 kg |
Spa Shell Material(USA) | Aristech ® Acrylic |
Spa Cabinet Material | PS Wood-Plastic Composite Panels |
Cabinet Frame | Preserve Woods+ stainless steel |
Bottom (Pedestal Base) | ABS sheet |
Jet Ring Trim | White Grey Plastic |
Total Jets (pcs) | 50 |
6' Rotational Jets (pcs) | 3 |
6' Directional Jets (pcs) | 5 |
4' Rotational Jets (pcs) | 2 |
4'' Directiona Jets(pcs) | 4 |
2.5' Directional Jets (pcs) | 36 |
Ozone Jets | 1 |
Joyonway Control system | P68B123 |
Joyonway Touch panel | PB565 |
Pump 1(CE, TUV Approved) | One-speed / 1*2.0HP |
Pump 2(CE, TUV Approved) | One-speed / 1*2.0HP |
Circulation Pump (CE, TUV Approved) | 1 x 0.5HP |
Heater(CE, UL Approved) | 1 x 3.0kW |
Lighting(ETL Approved) | 1x12V, Multi-colored LED Underwater Light |
Ozone Water Purification System | Yes |
Electrical Requirements | 220-240V/50Hz, 22A Max. |
Filter Size | 50sq.ft. |
2' Diverter Valve(pc) | 2 |
1' Diverter Valve(pc) | 2 |
Air Control Valves (pcs) | 4 |
EVA Spa Pillows(pcs) | 3 |
Bottom Drain(pc) | 1 |
Drain Valve(pc) | 1 |
Couples in Small Homes
One partner takes the lounger for a full-body float; the other sits upright. Unlike 2-person spas, you still have three extra seats for when friends visit.
Urban Rooftop Decks
The 2130×2130mm base fits standard elevator dimensions and rooftop access doors. Lighter than full-size lounger spas, it's feasible for buildings with limited crane access.
Runners and Cyclists
The 36 micro-directional jets along the lounger's leg well target the exact muscles that endurance athletes abuse daily—calves, hamstrings, and arches.
Physical Therapy Practices
Clinics with limited floor space can offer both upright seating and a rehab lounger. Patients with mobility issues find the lounger easier to enter than deep upright seats.
Vacation Rentals (Cabins/Tiny Homes)
Rural rental properties with small decks can add a premium amenity without major construction. Guests searching for "hot tub cabin" will pay a premium for a lounger-equipped spa.
First-Time Spa Owners
Entry-level buyers often worry that a lounger will dominate their yard. The V1005 proves otherwise, offering the luxury feature without the oversized footprint.
Installation Requirements
Electrical: 220-240V / 50Hz, 22A dedicated circuit with GFCI/RCD.
Foundation: Reinforced concrete pad, 100mm minimum thickness, supporting 1,811 kg.
Access: The 2130×2130mm base passes through standard garden gates (900mm+ openings) when delivered diagonally.
Getting Started
Position the empty V1005 on its concrete foundation.
Connect electrical supply through a licensed electrician.
Fill through the filter compartment until water covers all jets.
Power on; set temperature to 38°C via PB565 panel.
Add startup chemicals per the quick-start guide.
Quick Tips
Lounger Optimization: Close the two upright seat diverter valves 50-75% to direct more pressure to the lounger's 36 micro jets.
Cover Management: Use the included cover whenever the spa is idle; heat loss doubles without it.
Winter Checks: In sub-zero weather, verify power remains on daily—a tripped breaker can freeze the spa within 24 hours.
Download Full Installation Manual (PDF) → [Click Here]
Q1: Is the V1005's lounger long enough for tall people?
A: The lounger accommodates users up to 190cm (6'3"). Taller individuals may find their heels extend past the final micro jets but still receive adequate massage.
Q2: How does the V1005 differ from the V1002?
A: V1002 has a 2260×2260mm footprint; V1005 is 2130×2130mm. V1005 has 50 jets (vs 56) but the same lounger length. Choose V1005 for tighter spaces, V1002 for larger yards.
Q3: Can children use the lounger safely?
A: Yes, but supervise children under 12. The lounger's depth means a small child's head may not clear the water surface; use upright seats for young bathers.
Q4: What's the warranty on the shell?
A: 5 years against cracks, blisters, or fading. The Aristech® acrylic is backed by the manufacturer's material warranty plus VIRLUX's workmanship coverage.
Q5: Does the ozone system eliminate chlorine completely?
A: No—ozone reduces chemical demand by ~70% but doesn't eliminate it entirely. A small residual sanitizer (chlorine or bromine) is still required.
Q6: Can I install the V1005 partially recessed into a deck?
A: Yes, but consult our engineering team. Recessing requires specific clearance for pump access and ventilation. Partial recess (down to cabinet midline) is easier than full recess.
Q7: How long does the filter last?
A: The 50 sq.ft. filter typically lasts 12–18 months with monthly rinsing. Replace when rinsing no longer restores flow.
Q8: Is professional installation mandatory for warranty?
A: Electrical connection must be performed by a licensed electrician to maintain the warranty. Physical placement can be DIY with helpers.
